Avestin - High Pressure Homogenisers | Liposome Extruders
High Pressure Homogeniser, Cell Lysis & Extruder Systems
Designed to deliver exceptional results whilst being user friendly and robust. The unique dynamic homogenising valve allows sheering pressures of up to 30,000 psi whilst minimizing the occurrence of blockages, allowing for uninterrupted processing.
Industries and Applications include:
Industries
Food and Dairy
Cosmetics
Nutraceutical
Pharmaceutical
Biotechnology
Chemical Processing
Applications
Cell lysis
Nano-emulsions
Particle size reduction and distribution
Drug delivery and nano-carries
Liposomal extrusion
Gold nanoparticles
Lab Scale
Avestin offers a comprehensive range of compact laboratory-scale homogenizers to meet the needs of a wide variety of applications. The B-15, C3, and C5 homogenizers are all designed for use in research and development laboratories, and they offer a variety of features to make them versatile and easy to use.
B15
3-15mL/hr Flow Rate
Up to 45,000 psi
3mL min. sample vol
C3
3L/hr Flow Rate
Up to 30,000 psi
10mL min. sample vol
C5
1-5L/hr Flow Rate
Up to 30,000 psi
10mL min. sample vol
Pilot Scale
The Avestin range of pilot machines offers an increased processing capacity to the lab scale using the same homogenising technology, meaning scale up is simple and easy to implement. Tailored for pilot use and small-scale production, these homogenisers allow users to achieve consistent high-quality results.
D20
20L/hr Flow Rate
D20 A up to 20,000 psi
D20 B up to 30,000 psi
50mL min. sample vol
C50
15-50L/hr Flow Rate
Up to 30,000 psi
25mL min. sample vol
C55
55L/hr Flow Rate
C55 A up to 20,000 psi
C55 B up to 30,000 psi
100mL min. sample vol
Production Scale
Engineered for large scale industrial application, the production range of Avestin high pressure homogenisers are purpose built for large scale processing up to 1,000L per hour whilst still offering the same precise homogenising technology that produces consistent high-quality results.
C160
160L/hr Flow Rate
C160. A up to 20,000psi
C160 B up tp 30,000 psi
250mL min. sample vol
C500
500L/hr Flow Rate
C500 A up to 20,000psi
C500 B up tp 30,000 psi
5L min. sample vol
C1000
1,000L/hr Flow Rate
C1000. A up to 20,000psi
C1000 B up tp 30,000 psi
5L min. sample vol
Get in touch today
Tel: +44 (0) 1962 841092 | bps@biopharma.co.uk
Liposome Extrusion Systems
Avestin's Liposome Extruder Range offers a comprehensive solution for the production of liposomes, which are microscopic spherical vesicles composed of phospholipids.
The range's ability to produce liposomes with controlled size and morphology makes it suitable for a wide range of applications, supporting the development of innovative liposome-based products.
LiposoFast-Basic & Stabilizer: This manual liposome extruder is designed for small-volume sample preparation (0.1mL to 1.0mL) and produces homogeneous unilamellar liposomes. It utilizes a track-etched polycarbonate membrane to control the size of the liposomes produced.
LiposoFast LF-50: This automatic liposome extruder is suitable for medium-volume sample preparation (5mL to 50mL) and produces homogeneous unilamellar liposomes. It features a temperature-controlled jacket to maintain sample temperature during the extrusion process, ensuring consistent liposome formation.
Liposome Extruder Accessory: This accessory transforms any Avestin high-pressure homogenizer, such as the C3, D20, C55 and production unit into a liposome extruder. It utilizes the high-pressure homogenizer's power to shear the lipid solution through a track-etched polycarbonate membrane to produce liposomes.
